DC blower fan type AV-F9733
SIZE:
97x97x33mm
CONSTRUCTION:
Glass fiber reinforced thermoplastic
Impeller and housing UL94V-0
OPERATING TEMPERATURE:
Sleeve bearing -10C to +70C
INSULATION RESISTANCE:
>10 megohm at 500VDC
(frame-terminal/wires)
DIELECTRIC STRENGTH:
500V/60HZ, 5mA, 1 minute
(frame-terminal)
|
MODEL |
BEARING TYPE |
RATED VOLTAGE (DC) |
OPERATING VOLTAGE (DC) |
CURRENT (A) |
SPEED (RPM) |
AIR FLOW (CFM) |
STATIC PRESSURE (mmH2O) |
NOISE LEVEL (dBA) |
WEIGHT (g) |
|
AV-F9733HS |
SLEEVE |
12 |
10.8-13.2 |
1.00 |
3200 |
24.90 |
23.06 |
48.83 |
146 |
|
AV-F9733MS |
SLEEVE |
12 |
10.8-13.2 |
0.60 |
3000 |
23.10 |
20.86 |
43.67 |
146 |
|
AV-F9733LS |
SLEEVE |
12 |
10.8-13.2 |
0.50 |
2600 |
20.10 |
15.03 |
34.34 |
146 |
|
AV-F9733HB |
BALL |
12 |
10.8-13.2 |
1.00 |
3200 |
24.90 |
23.06 |
48.83 |
146 |
|
AV-F9733MB |
BALL |
12 |
10.8-13.2 |
0.60 |
3000 |
23.10 |
20.86 |
43.67 |
146 |
|
AV-F9733LB |
BALL |
12 |
10.8-13.2 |
0.50 |
2600 |
20.10 |
15.03 |
34.34 |
146 |
|
AV-F9733HS24 |
SLEEVE |
24 |
21.6-26.4 |
0.60 |
3200 |
24.90 |
23.06 |
48.83 |
146 |
|
AV-F9733MS24 |
SLEEVE |
24 |
21.6-26.4 |
0.40 |
3000 |
23.10 |
20.86 |
43.67 |
146 |
|
AV-F9733LS24 |
SLEEVE |
24 |
21.6-26.4 |
0.30 |
2600 |
20.10 |
15.03 |
34.34 |
146 |
|
AV-F9733HB24 |
BALL |
24 |
21.6-26.4 |
0.60 |
3200 |
24.90 |
23.06 |
48.83 |
146 |
|
AV-F9733MB24 |
BALL |
24 |
21.6-26.4 |
0.40 |
3000 |
23.10 |
20.86 |
43.67 |
146 |
|
AV-F9733LB24 |
BALL |
24 |
21.6-26.4 |
0.30 |
2600 |
20.10 |
15.03 |
34.34 |
146 |
